Crompton 7.5HP Motor

Name: Crompton 7.5HP Motor
Brand: Perfect Engineering Solutions
Price: 19578 INR
Availability: InStock

Price 19578 INR/ Number

Get a Price/Quote

MOQ : 1 Number

Crompton 7.5HP Motor Specification

Power Rating
5.6 kW

Pressure
Atmospheric

Features
Squirrel Cage, Low Vibration, Robust Design

Cooling Method
Fan Cooled

Horse Power
7.5 HP

Starting Type
DOL

Torque
47 Nm

Current Type
AC

Bearing Type
Deep Groove Ball Bearing

Noise Level
Less than 75 dB

Motor Type
Induction Motor

Rated Voltage
415 V

Standard
IS: 325

Poles Number
4

Efficacy
IE2 Efficiency

Voltage
415 V

Sealed Type
Totally Enclosed Fan Cooled (TEFC)

Ambient Temperature
Up to 50°C

Rated Frequency
50 Hz

Product Type
Electric Motor

Output Power
7.5 HP

Frequency (MHz)
50 Hz

Protect Feature
Thermal Overload Protection

Phase
Three Phase

Speed
1440 RPM

Power
5.6 kW

Color
Blue

Dimension (L*W*H)
Approx. 700 x 250 x 350 mm

Weight
68 kg

Shaft Diameter
38 mm

Mounting Type
Foot Mounted

IP Rating
IP55

Connection Type
Star or Delta

Frequency Tolerance
±5%

Phase Sequence
ABC

Duty Cycle
S1 Continuous Duty

Material of Construction
Cast Iron

Temperature Rise
Limited as per IS Standards

Rotor Type
Copper Bar

Application
Industrial Equipments, Pumps, Compressors, Fans

Efficiency at Full Load
88.1%

Vibration Level
Below Standard Limits

Frame Size
132M

Insulation Class
Class F

Service Factor
1.0

Crompton 7.5HP Motor About

Shop now to experience the lavish power of the Crompton 7.5HP Motor, built for world-class performance in demanding industrial environments. Crafted from glorious cast iron, this robust induction motor delivers a value-packed 5.6 kW output with an impressive IE2 efficiency of 88.1% at full load. With markdown pricing, you get a totally enclosed fan-cooled (TEFC) operation, oversized deep groove ball bearings, and thermal overload protection. Rely on a glorious and reliable solution for pumps, compressors, fans, and more, meeting international standards and ready for continuous duty. Value, reliability, and excellence combined.

Versatile Applications Across Industrial Surfaces

Widely used by leading distributors, manufacturers, service providers, and suppliers throughout India, the Crompton 7.5HP Motor is perfect for application surfaces like industrial floors and factory settings. Its expert design makes it highly suited for diverse application media, including fluids managed by industrial pumps, compressed air from compressors, and ventilation by fans. This world-class motor thrives in rigorous industrial environments, delivering outstanding results across multiple sectors and large-scale operations.

Certified Excellence and Global Export Logistics

With IS: 325 standard certification and robust build quality, the Crompton 7.5HP Motor is trusted by clients globally. Its main export markets include Asia, Africa, and the Middle East, ensuring a wide reach at a competitive sale price. Each unit is securely packaged in durable wooden crates for safe, reliable logistics and delivery. Depend on a product that balances quality assurance with seamless shipping, catering to the needs of various industries around the world.

FAQ's of Crompton 7.5HP Motor:

Q: How does the Crompton 7.5HP Motor enhance industrial applications?

A: The Crompton 7.5HP Motor provides excellent efficiency, low vibration, and a robust cast iron structure, making it ideal for rigorous industrial applications such as operating pumps, compressors, and fans.

Q: What are the protection features included in this motor model?

A: This motor is equipped with thermal overload protection, IP55 ingress protection, and a totally enclosed fan-cooled (TEFC) design, ensuring safety and reliable operation in demanding environments.

Q: Where can this motor be best utilized?

A: The Crompton 7.5HP Motor excels in various industrial settings-including production plants, water pumping stations, and processing facilities-where continuous, dependable performance is required.

Q: When should I consider using the Star or Delta connection type?

A: The choice between Star and Delta connection depends on your start-up and operational needs; typically, Star connection is used for starting to reduce current, while Delta is chosen for full load operation to maximize efficiency.

Q: What international certifications and standards does the Crompton 7.5HP Motor meet?

A: This motor complies with the IS: 325 standard and features IE2 efficiency, aligning with global quality and energy-efficiency standards for safe industrial operation.

Q: How is the motor packaged and shipped for export?

A: For logistics and export, each Crompton 7.5HP Motor is packed in sturdy wooden crates, ensuring safe and damage-free delivery to major markets in Asia, Africa, and the Middle East.
